EMS61000-11B DC Voltage Dip Generator




















The EMS61000-11B intelligent DC voltage dip generator is a high-reliability voltage dip generator specifically designed to meet the characteristics and requirements of immunity tests for voltage dips, short interruptions, and voltage variations on DC power supply input terminals. It features rich functionality and easy operation.



Technical Features of EMS61000-11B Intelligent DC Voltage Dip Generator:


1. TFT LCD display with user-friendly interface;

2. Precision programmable voltage source design, enabling arbitrary voltage dips and variations;

3. Equipped with EUT voltage and current observation terminals for real-time monitoring;

4. Unique high-impedance and low-impedance mode switching to simulate grid faults realistically;

5. Can store 8 sets of settings;

6. RS232 communication, providing a test software platform.











Hangzhou Everfine EMS61000-11B DC Voltage Dip GeneratorTechnical Specifications:

























































Model
EMS61000-11B

Rated Voltage
0V~50V DC

Voltage Dip Level
0%~120%

Test Mode
Voltage Dip / Voltage Variation

Fall Time
0.01s~60.00s (0.01s/step)

Duration
1ms～9999ms (1ms/step)

Rise Time
0.01s~60.00s (0.01s/step)

Repeat Interval
0.00s～60.00s

Repeat Count
1~9999

Voltage Change Rise/Fall Time

(100Ω Load)
1μs～5μs

Trigger Mode
Manual / Automatic

EUT Capacity
3A max

Communication Interface
RS232
